Auto Thermal Bonding Machine Padding Mattress Production Nowoven Drying Oven

Ask Lasest Price
Brand Name :	AL
Model Number :	Thermal Bonding Machine
Certification :	CE/ISO9001
Price :	USD 32000 SET
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	10 SET YEAR
Delivery Time :	70 work days

Add to Cart

Product Details
Company Profile

Auto Thermal Bonding Machine Padding Mattress Production Nowoven Drying Oven

Nowoven drying oven,polyester wadding,Thermal Bonding Oven Nonwoven Machine

Nonwoven thermal bonded padding mattress production line

Product Description

The stiff waddings produced by this machine unit is replacement of sponge,used for exclusive mattress,sofa cushion,tatami,filtering material and acoustic flet,etc. The stiff waddings dryer adopts stainless steel chain plate structure,to ensure the smoothness and flatness of product surface.

Auto Thermal Bonding Machine Padding Mattress Production Nowoven Drying Oven

Main Features

1) Net product width: 2300mm, 2500mm, 3200mm

2) Product specification: 80-1000g/m2.

3) Production capacities: 80-200kg/h.

4) Heating source: heat-conducting oil, direct ignition.

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Certifications

Detailed Images

Double cylinder double doff carding machine

Working Width: 1850mm
Mechanical type: double cylinder double doffer four random
Proper fiber specification:1.5D-7D
Main cylinder diameter 1230mm with 5 sets working zones.
Four rollers feeding with frequency control, installed with anti-metal alarm and auto-reverse function.

ALHX, OVEN MACHINE

OVEN length: 6000-8000mm

Working width: 2800mm-2800mm

Working temperture: ≤220℃

Working speed: 1-10m/min

Feeding type: gas, heating,oil,electricity

Cross Lapper machine

Effective output width≤3000mm
Input Lattice length: 2000mm(anti-skidding PVC belt)
Output Lattice length:2900mm
Bottom lattice: Bamboo lattice, lift range: 500mm
All the horizontal moving rollers adopt seamless steel pipes

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
